Trimmer pots
-
50K, Piher PT15 with 4x3mm groove€0.50 €0.40Encapsulated 1-turn trimmer with carbon track. Supplied with grooves 4x3 mm for an additional knob or spindle. The capsule protects against dust, damp, flux, and detergents etc. PCB mounting. Learn MoreSKU: 6521-50KManufacturer: Piher -
-
- 10K, Piher PT15 with 4x3mm groove€0.50 €0.40Encapsulated 1-turn trimmer with carbon track. Supplied with grooves 4x3 mm for an additional knob or spindle. The capsule protects against dust, damp, flux, and detergents etc. PCB mounting. Learn MoreSKU: 6521-10KManufacturer: PiherResistance: 4
-
-
-
-
-
-
- PT15GW-35, knob / shaft for Piher PT15N / 4x3 trimmer€0.35 €0.28SKU: 6521-PT15GW-35Manufacturer: Piher
- 500 k, Piher PT15 with 4x3mm groove€0.50 €0.40Encapsulated 1-turn trimmer with carbon track. Supplied with grooves 4x3 mm for an additional knob or spindle. The capsule protects against dust, damp, flux, and detergents etc. PCB mounting. Learn MoreSKU: 6521-500kManufacturer: Piher
- 5k multiturn pot, vertical€0.35 €0.28Power 500mW
Tolerance ±10%
Characteristics linear
Track material cermet
Operating temperature -55...125°C
Terminal pitch 2.5x2.5mm
Body dimensions 10 x 9.5 x 4.8mm
Number of mechanical turns 28
Mechanical durability 200cycles Learn MoreSKU: 658-T910Y-5K - 2.5M "upright", Piher PT15 with 4x3mm groove€0.52 €0.42Encapsulated 1-turn trimmer with carbon track. Supplied with grooves 4x3 mm for an additional knob or spindle. The capsule protects against dust, damp, flux, and detergents etc. PCB mounting. Learn MoreSKU: 651-2M54x3Manufacturer: Piher
-
- 100k multiturn pot, vertical€0.35 €0.28Power 500mW
Tolerance ±10%
Characteristics linear
Track material cermet
Operating temperature -55...125°C
Terminal pitch 2.5x2.5mm
Body dimensions 10 x 9.5 x 4.8mm
Number of mechanical turns 28
Mechanical durability 200cycles Learn MoreSKU: 658-T910Y-100K - 50k multiturn pot, vertical€0.35 €0.28Resistance 50kΩ
Power 500mW
Tolerance ±10%
Characteristics linear
Track material cermet
Operating temperature -55...125°C
Terminal pitch 2.5x2.5mm
Body dimensions 10 x 9.5 x 4.8mm
Number of mechanical turns 28
Mechanical durability 200cycles Learn MoreSKU: 658-T910Y-50K - 10k multiturn pot, vertical€0.35 €0.28Power 500mW
Tolerance ±10%
Characteristics linear
Track material cermet
Operating temperature -55...125°C
Terminal pitch 2.5x2.5mm
Body dimensions 10 x 9.5 x 4.8mm
Number of mechanical turns 28
Mechanical durability 200cycles Learn MoreSKU: 658-T910Y-10K -
- 250ohm, Piher PT15 with 4x3mm groove€0.50 €0.40Encapsulated 1-turn trimmer with carbon track. Supplied with grooves 4x3 mm for an additional knob or spindle. The capsule protects against dust, damp, flux, and detergents etc. PCB mounting. Learn MoreSKU: 6521-250Manufacturer: Piher
